SSR electronic load relay 30 A / 20 A
HE series
The HER load relay is a ready-to-install electronic power actuator for electrical heating systems. It is intended for continuous use with high switching frequency. In contrast to an electromechanical relay or contactor, no wear of switching contacts is possible here.
The HER is prepared for use on a top-hat rail (TS 35), completely equipped with heat sink and over-voltage protection.
Load voltage | 230 V AC |
HER 30 D load current | 0.2 – 30 A AC 1 at < 40 °C |
HER 20 D load current | 0.2 – 20 A AC 1 at < 40 °C |
Protection type | IP20 (EN 60529), protection class II |
Connection terminals | 2.5 mm² / 4 mm² |
Housing dimensions | 81 x 22.5 x 100 mm (H x W x D) |
Type | Control voltage |
HER | 4 – 32 V DC |
