Glass-fibre reinforced polyester housing for use in explosion hazard areas
Ex connection housing HBR-QX
Ex connection housing made of glass-fibre reinforced polyester for connecting self-limiting heating conductors, single-wire heating conductors and mineral-insulated heating conductors. The connection housings are available in many different versions for all common uses. Usage under extreme environmental conditions, aggressive chemical media and severe mechanical stresses are no problem for these robust distributor housings.
- Temperature stable
- Chemical resistant
- Antistatic
- 2 + 6 + 8 terminals 4 mm²
- Corrosion resistant / UV-resistant
Dimensions HBR-QX-P1 HBR-QX-P5 |
80 x 75 x 55 mm ( LxWxH) 122 x 120 x 90 mm |
Protection type | IP65 |
Min. ambient temperature | -40 °C (-55 °C on request) |
Temperature class | T6 at +50 °C T5 at +55 °C T4 at +60 °C |
Marking | (Ex) II 2G D, II 1G-D, T6 Exe/Exi |
